HELIOGRAPH

Fusion of metal and light. A thick bar of acrylic is bisected by a wide band, delivering clear illumination from integrated LEDs.

• CRI: 90
• Input: 120/277V, 50/60Hz
• ELV Dimming: 100-10%
• TRIAC Dimming: 100-10%
• Rated Life: 50000 Hours
• Up, down, and ambient illumination
• Clear acrylic blocks are softened with an etched facade to diffuse light
• Built in color temperature adjustability. Switch from 2700K/3000K/3500K/4000K
• Option to pre-select color temperature or adjust in the field
• Driver concealed within the canopy
• Can be mounted on wall in all orientations
